Applicable PCB: L510mm x W460mm to L50mm x W50mm
Number of component types: Tape package components: 106 types
package conversion: 15 types（Max/JEDEC tray conversion）
Applicable components: 0402 to 45x100mm, including ball type
needs special nozzle set
Applicable height: 15mm
Power supply: 3-Phase AC 200/208/220/240/380/400/416 V +/-10%
Air supply source: 0.45MPa
External dimension: L1,254 x W1,755 x H1,475mm （when ATS15
mounted; not include the projection）
Weight Approx. 1,370kg （when ATS15 mounted）
electrode components *32x32mm or more（Max/8mm tape reel conversion）Tray
Mounting accuracy: Absolute accuracy（μ＋3σ） +/-0.05mm/CHIP
Mounting tact: 20,000CPH（under our optimum condition）
Component supply: Tape reel, tray
